Harga GPS Geodetik Topcon GR5 GNSS RTK & Static Call 0812-8222-998




TAKING ADVANTAGE OF ALL AVAILABLE GNSS SYSTEMS, NOW AND TOMORROW

The combination of a compact form factor, revolutionary Universal tracking technology, and multiple communication methods makes the Topcon GR-5 receiver the most popular and versatile option for high precision GNSS reliability.
  • Capable of tracking GPS, GLONASS, BeiDou, Galileo, QZSS constellations
  • Universal Tracking Channels capable of all-in-view tracking
  • Track every satellite constellation above today and tomorrow
  • Signal scrubbing Fence Antenna® to provide ultimate signal lock
  • Highest accuracy positioning for RTK, network, and more
  • Offers choice of UHF or Spread Spectrum radios, as well as an optional, internal cellular modem for all your project needs

GR-5 Specifications

GNSS Tracking
Signals Tracked*
GPS, GLONASS, Galileo*, BeiDou*, SBAS, and QZSS
Number of Channels
226-Channel Vanguard Technology™ with Universal Tracking Channels
*A Positioning solution with these signals will be integrated and made available when the constellation matures and is ready for commercial use.
Accuracy
Accuracy
Static/Fast Static:
H: 3.0 mm + 0.4 ppm
V: 5.0 mm + 0.5 ppm
*
Precision Static:
H: 3.0 mm + 0.1 ppm
V: 3.5 mm + 0.4 ppm
RTK (L1+L2):
H: 5 mm + 0.5 ppm
V: 10 mm + 0.8 ppm
*See brochure for more information.
Communications
Base radio output
1.0W
Cellular*
Integrated HSPA+/CDMA
I/O Communications
Class 2 Bluetooth®
USB and Serial
*Optional
Data
Memory
Removable SD/SDHC Card
Real Time Data Output
TPS, RTCM SC104 v2.x, 3.x and MSM, CMR/CMR+
ASCII output
NMEA 0183 version 2.x, 3.x and 4.x
Physical and Environmental
Enclosure
Magnesium I-Beam Housing
Operating Temperature*
-30ºC to 70°C
*-30ºC to +60°C with integrated batteries.
Certifications and Standards
Shock Rating
2 m pole drop to concrete
IEC 60068-2-29
IEC 60068-2-27
Vibration Rating
Compliance with MIL-STD 810F - 514.5-Cat.24
