Jual GPS Geodetik Topcon Hiper SR (GNSS RTK & Static)





Lightweight yet tough enough to survive a 2m drop, and enough rechargeable batter for 20 consecutive hours of operation! The new HiPer SR with optional cellular configuration adds tremendous opportunities to your job site. Topcon''''s HiPer SR integrated receiver operates cable free, with no antennas, battery doors, or connectors. HiPer SR features the 226 channel, universal tracking capable Vanguard chip for unmatched performance flexibility to meet the needs for all jobs, large or small. Use a single SR for fast and accurate static GNSS or as a network RTK by adding network functionality and cellular enabled controller. Use a pair for an economical base and rover RTK solution or with Topcon''''s LongLink communication solution for the perfect small site-wide solution. The best part? There''''s a HiPer SR to fit your budget.
Power. Performance. Price. With the HiPer SR, it all fits in the palm of your hand.

Features include:

226-channel Vanguard technology with Universal Tracking Channels
Hybrid Positioning capable
Compact, lightweight, rugged design
Completely integrated receiver, antenna, batteries, memory, and communications
Integrated multi-channel LongLink communication technology
Sealed battery providing up to 20 hours of operation
Reduced MINTER display, with single-button operation
Charging (serial and power) and USB ports only
Cellular (optional) configuration


Positioning accuracy:
>> Static Accuracy
- Horizontal ( 3 mm + 0.8 ppm RMS )
- Vertical ( 4 mm + 1 ppm RMS )
>> RTK Accuracy
- Horizontal ( 10 mm + 1 ppm RMS )
- Vertical ( 15 mm + 1 ppm RMS )

Long Range RTK technology with Bluetooth R: 300 Meter , Daiameter : 600 Meter
One Base can be connected with 3 simultaneous Rover
Internal Memory 4 GB
RTCM Version 2.x module has input and output 3.x, NMEA and NTRIP
Dust and water protection IP 67
Shock Rating : 2 pole drop concerte
Operating Battere : approx 20 hour for static Mode
Available a Lamp Indication for Total Satelite, memory, battery life and data communications
Able do a direct depiction of a line, point and polygon when survey measurements
Able To display information form fields, area and perimeter of the field, the length of the boundary line,
Able to import point data from an excel and do a stake out point for reconstruction
Able to import image data and perform stake out directly from the Image Field
Able to display the background base map of raster and vector
Layer can be made directly in the field and can be read on an existing CAD software
Able to import and export files in the form of shp, dxp, DWG, csv, txt, etc.


Specifications
Tracking
Number of Channels 226 Channels Vanguard Technology with Universal Tracking Channels
Signals Tracked

GPS: L1, L2, L2C
GLONASS: L1, L2, L2C
SBAS - QZSS: L1, L2C
Antenna Type Integrated Antenna with
Fence Antenna Technology
Positioning Accuracy*
RTK (L1+L2) H: 10 mm + 1.0 ppm
V: 15 mm + 1.0 ppm
Fast Static (L1+L2) H: 3 mm + 0.5 ppm
V: 5 mm + 0.5 ppm
DGPS H: 0.4 m, V: 0.6 m
SBAS H: 1.0 m, V: 1.5 m
Communication
RTK Broadcast LongLink 300m+ Range,
Up to 3 simultaneous rovers
I/O Communications Bluetooth, Serial, USB
Cellular Integrated HSPA+ (Optional)
Dual Sim Card available
Data & Memory
Memory 2GB internal
Data Update/Output Rate Up to 10Hz
Real Time Data Output TPS, RTCM SC104 v 2.x, 3.x;
CMR/CMR+
ASCII Output NMEA 0183 version 2.x and 3.0
Physical
Dimensions (w x d x h) 6 x 6 x 2.5 in.
150 x 150 x 64mm
Weight 1.87 lbs. (850g) Basic
2.04 lbs. (925g) Cellular
Status Display / Panel MINTER
External Power Connector Yes
Operation Time Up to 20 hours
Power Supply
Operation Time Up to 20 hours
Environmental
Operating temperature -20C to 65C
with internal batteries
-40C to 65C
with external power
Storage temperature -40C to 70C
Humidity 100%, condensing
Water / Dustproof

CONTROLER FLINT S300
Peosesor 800 MHz
Operating system : OS Microsof window Mobile 6.5 Pro

RAM 256 MB, Flash Memory 2 GB dan external Memory Slot Micro SD 4 GB480x640px (VGA)
Displaey 3.5 color LCD BLANVieW Transmissive
Available Camara 5 Mega pixel auto focus kamera Resolution: 1280 x 960, 2048 x 1536
Communication : Bluettoth GAP, SDP, GOEP, DUN, SPP, OPP, A2DP, PAN, HID
GSM cellular Phone has Available
wireless Lan IEEE 802.11 b/g 54 Mb/s,USB OTG
Available Internal GPS with channnal 50,GPS L1 Frequency, C/A Code
Internal Accuracy 1-3 Meters (Autonomous), 1-2 Meters (SBAS), < 1 Meter (NTRIP/eGPS)
Shock Rating : 2 m pole drop to concrete
Dust and water protection:Per IEC 60529 Ed. 2.1:2001-02, IP65, 8 hours dust, 10 mins. Water
operating Battere 6 hour,Lithium-ion Polymer, 3.7V, 2,600mAh, USB charging thru
PCs supported
Initialization to fix: cold star: 29 s, warm star : 29 s, Hot star <1 s

Paket Pembelian :

2X Kit Hiper SR
2X OAF HIPER SR
1X Magnet field GPS
1X Tribrach 10
1x Litepole
1x Data Controller Flint S 300 ( Pengambil data )
1X On pole bracket fro Pole
1x Hi Rod
1x Allumunium Tripod
1x Software Post Process ( Magnet office Tools )
